Stainless Steel Medical Scrub Sink Stations for Hospital Operating Theatres

1>Medical scrub sink

2>Used in surgical operation

3>For serveral doctors

WORKING PRINCIPLE :
Water directly passed through the scrub station, and filled in water reservoir where the heaters are fixed with thermostatic arrangement with water level sensor. This sensor controls the water level and switch off the solenoid.

It works on optical sensor where a person stand in front of the water tap signal to solenoid and open the water to scrub. Similarly soap and dry air arrangement is working.

Scrub stations are made available in different sizes of different models for 1/2/3/more persons.
OPTIONS :

A water filter in the form, to be fixed before the water enters the tank.
  - A Voltage stabilizer.
  - A Sterile Air System for drying the hands etc.
TECHNICAL DETAILS
Input: ~220V, 50/60Hz; ~110V, 50/60Hz
System work on microprocess control
Heater: 2000 W with Thermostat.
Motor: 1/8 H.P
Temperature: Maximum 50 degree C with thermostat control
Water tank capacity: 40~80 Liters.
Jet wash: Optional switch

Optional Accessories
  - SOAP CAKE STAND
  - TOWEL HANGER (S.S)
  - BRUSH BASIN STAND (S.S)

SCRUB STATIONS can also be FABRICATED to be FOOT OPERATED MANUALLY / KNEE OPERATED MANUALLY.

More details~

Material: Stainless Steel (ASTM 304)

Dimension: 2400X600X1800(mm) - Dimension Customized

Flux: 1500L/Hour

0.1μm Filters for the water;

Automatic Sensors controlling Water Supplying;

Automatic Sensors controlling Liquid Soap Supplying;

Mirror;

Fluorescent Lamp;

Built-in Leakage Protection Device;

Optional Function:

Knee Touch Button Controlling for water supplying;

Foot Touch Button Controlling for water supplying;

Electrical Water Heating System;

Automatic Scrub Box;

Photos as follows:

Two Person Hospital Scrubs Sink Station

One Person Hospital Scrubs Sink Station

What advantages we have:

1, We are the professional manufacturer for more than 8 years;

2, We produce and supply series of equipments, the importers do not need to look for and purchase from many different suppliers;

3, We have years of experience for Medical Gases Engineering Projects, we know all the details for the hospital gases engineering projects, and we will not neglect the details;

4, Strict standard, and quality management: all our products are produced according the standard, and we know the different standards for different countries well;

5, Professional Engineerers team: we can design, and customize the products as the hospitals requests; Also, sometime, we check for and advise the requests to the clients;

6, Economies of scale: as the professional and big manufacturer, we have advantage for Economies of Scale;

7, Professional Exporting Team: we export the products to more than 30 countries in the last several years. We know the requests from different countries customs;

System Advantage:

1. Advanced independent coding method: All calling & intercoming extensions are mutually compatible, and can be replaced or exchanged. By programming in the system host machine, number of all extensions can be changed by nurses (Simple programming online). Extension number can be set up as 2 bits, 3 bits, or 4 bits (such as, setting up the 4 bits of 0308 to show No.8 patients in No.3 ward);

2. There is erasable memory chip in each extension. It helps to realize recoding function without exchanging chips;

3. Conceal / Surface Intalling optional: different extension models for conceal or surface installing;

4. Wireless Calling function is expandable: with wireless receiver (hand held / watch Type), nurses can process callings

Optional products for patient & nurse call system:

1.toilet calling extension,used in the toilet,for patient to call when emergency.

2.single color light alarm.it used on the patient room door.when patient called,the light is flashing.

About us~

1>Our facotry specilized in Medical Pendant ,Which mainly used in the Hospital Operating Theatres (OT), or Intensive Care Units (ICU). They are ceiling mounted, Including Medical Gas Outlets, Electric Sockets, Communicate Ports, with shelves and drawer etc.

2>We also supply the different standards for the gas outlets.Include the British/french/South African/American/German,etc

3>Another,We supply some other equipment of the hospital.Any needs.pls feel free to emaiil us.

4>We are the original facotry.Accept customized:)
